22-20 FIREWOOD PROCESSOR
- • 3+ Cords/Hour
- • Logs up to 24″ Diameter & 20′+ Lengths
- • 66HP Doosan Diesel Engine
starting at
$77,800
product details
Blockbuster 22-20 Firewood Processor
The Blockbuster 22-20 firewood processor is a versatile mid-size machine designed for commercial firewood operations that need reliable, efficient wood processing. Powered by a robust 66HP Doosan diesel engine, this processor delivers impressive performance, processing 3+ cords of firewood per hour and handling logs up to 24" in diameter and 20'+ in length.
Build your 22-20 Firewood Processor
Starting at $77,800
Standard Features
- 66 HP 4-Cyl. Turbocharged Doosan Diesel Engine
- 5″ Splitting Cylinder for Maximum Splitting Power
- 3-Strand Hydraulic Powered Log Deck
- Adjustable Splitting Head, Your Choice of One: 4-, 6- or 8-Way
- Chain-Driven Log Infeed Trough
- Hydraulic Saw 18H 90cm Harvester Bar and Chain
- Last Piece Slide Tray
- Air Compressor
- Single Axle Complete with Electric Brakes
- Running Lights for Transporting
- Firewood Clean-Out Grate
- Hydraulic Oil Cooler
- Toolbox
- Saw Dust Chute
- Operator’s Seat
- Elevator Hydraulics
- Extended Folding Operator’s Platform
- Cuts Up to 24″ Diameter
- Splits Wood from 12” to 22” Lengths
- Maximum Splitter Opening 24”
- Width – Transporting – 8′
- Width – Operating – 11′
- Height – Transporting – 8′ 4″
- Deck Height – 5′ to Top of Deck
- Length – 25′ 6″
- Weight – Approximately 7,900 lbs.
- 3-Strand Log Deck – 8′ Long
- Infeed Log Trough – 14′
- Hydraulic Tank Capacity – 33 Gallons
- Fuel Tank Capacity – 25 Gallons
- Splitter Cycle Time 5 Seconds
Featured Benefits
Split Over 3 Cords of Firewood an Hour
As a versatile mid-size industrial firewood processor, the Blockbuster 22-20 delivers reliable productivity. Powered by a robust 66 HP 4-cycle turbocharged Doosan diesel engine, this commercial-grade machine processes 3+ cords of firewood hourly. The chain-driven log trough ensures continuous log access, while its innovative features and efficient design maximize woodcutting performance.
Easily Transport from Site to Site
This industrial firewood processor is designed for maximum portability. Adjustable height stiff-legs and easy-to-use manual folding deck arms enable quick transitions between transport and operation modes, making it ideal for commercial loggers and firewood businesses that need to move between multiple wood piles.
Easily Transport from Site to Site
This industrial firewood processor is designed for maximum portability. Hydraulic stiff legs double as a positioning support and tongue jack, allowing rapid setup and leveling at any location. The log deck’s hydraulic system enables quick transitions between transport and operation modes, making it ideal for commercial loggers and firewood businesses that need to move between multiple wood piles.
Onboard Air Compressor
The Blockbuster firewood processors use an integrated air compressor to replace some traditional hydraulics, simplifying machine design and improving operational efficiency. With one lever, the system automatically lowers the log clamp, starts the saw motor at a set pressure point, and activates the saw cylinder; upon release, the saw automatically stops and retracts out of the way, while keeping the log clamp engaged. If equipped, the auto-stop feature will also automatically retract when the saw cut is complete. The air system enables a unique to the industry, one-touch splitting cycle; allowing operators to pull one detent lever to split and move on to cutting another log. The onboard compressed air system allows for convenient machine cleanup and tire maintenance.
User-Friendly Maintenance
User-Friendly Maintenance
Built to Last
Built with the Operator in Mind
Built with the Operator in Mind
Power Up: Maximize Your Processor with these Accessories
See the 22-20 Firewood Processor in Action
Cuts up to 24" diameter
Splits wood from 12" to 22" lengths
Capable of producing 3+ cords per hour (128 cubic foot cords)
Splitter cycle time 5 seconds
